Gold Platinum High Deck Tilt Trailer - Single Axle - 2000 kg

No expense is spared when we manufacture a Gold Platinum Tilt Trailer. We combine rugged ramp-less tilt design with a punch plate floor and a Soft Ride Independent Suspension System. All components used are of the highest quality

KEY FEATURES

• 2000 kg ATM
• Ramp-less Design
• 13 Degree Approach Angle
• Steel Punch Plate Floor
• Fixed Wheel Guards
• Soft Ride Independent Suspension
• 16" - 60 Series Tyres for Improved Ride
• 12" Disc Brakes rated to 2727KG
• Hot Dip Galvanised Chassis
• Landcruiser Sized Bearings
• Wide Tracks to suit large and small vehicles with no adjustment necessary
• Rear fold down flap for easy loading and allows our trailers to meet the rear visibility regulation
• 185cm Wide Deck
• Your Choice of Hydraulic or Electric Brakes
• LED Lighting
• Spare Wheel
• Jockey Wheel

OPTIONS

• Aluminium Checker Plate Floor
• Aluminium Expanded Mesh Floor

• Winch
• Stone Guard

• Custom Sizes Available

SUPPORT

• 15 Year Structural Warranty
• Full Length Commercial Warranty
• Free First Service
• Free Storage

SUSPENSION

• Torsion axles work by using rubber cords or cartridges inside the axle tube to handle suspension travel and shock absorption. Torsion axles do not use leaf springs, but instead the compression of the rubber to supply the suspension support needed. Each wheel works independently from one another.

VEHICLE STANDARDS

• Our trailers fully meet the Australian Vehicle Standards. We note that some other trailers on the market do not, leaving the owner with the risk of a fine, defect or invalid insurance. These regulations are where some manufacturers do not comply:



• VSB1 (Revision 6) 5.1.1 - Rear overhang must not exceed front load space.

• VSB1 (Revision 6) 6.5.8 - Visibility Requirements - the parts of the mudguards visible from behind must be coloured white or silver if the trailer is not fitted with rear marking plates & must have a white or silver band 75mm deep across the full width of the rear of the trailer. (markings plates are the red and yellow signs commonly seen on trucks)
• VSB1 (Revision 6) 5.2 - Width - Maximum width is 2500mm

PICK UP & DELIVERY

• Pick up is from Regency Park, SA
• Australia wide delivery is available
